Product Specification: CAT-5E 4x2x0.50,
Model: HY-FTP5-CA / HY-SFTP5-CU
Conductor Material: Bare Copper or CCA
Conductor Diameter:0.50mm±0.002mm;
Insulation: 0.9-0.92mm HDPE
Shield: Alumium Foil+0.4mm drain wire
Shield: 80*0.12mm or 96*0.12mm AL braids
Jacket: PVC/LSZH/CMR;
Wire Size: 5.6mm+0.2mm;
Packing: 305m/box
Characteristic impedance: 1 – 100 MHz : 100±15 Ohms
Operating Temperature: -20 to 75℃
Pulling Tension(Max): 25-30 lbs(133N)
Standard: ANSI/TIA/EIA-568B.1 or ANSI/TIA-568-C.2 ,ISO/IEC 11801 ;
Quality inspection Requirements:
Pass Fluke channel or pass Perm Link test and 305m network continuity test;
Product Certification: CE ROSH ISO Approved
Application Support:
IEEE 802.3 ; 100Base-T 1000Base-T; 155 Mbps ATM
