Product Specification: CAT6 4x2x0.57,
Model :HY-UTP6-CA / HY-UTP6-CU
Conductor Material: Bare Copper or CCA
Conductor Diameter:0.57mm±0.002mm;
Insulation: 0.98-1.02mm HDPE
Jacket: PVC/LSZH/CMR;
Wire Size: 5.8mm+0.2mm;
Packing: 305m/box
Characteristic impedance: 1 – 250 MHz : 100±15 Ohms
Operating Temperature: -20 to 75℃
Pulling Tension(Max): 20-25 lbs(110N)
Standard: ANSI/TIA/EIA-568B.1 or ANSI/TIA-568-C.2 ,ISO/IEC 11801 ;
Quality inspection Requirements:
Pass Fluke channel or pass Perm Link test and 305m network continuity test;
Product Certification: CE ROSH ISO Approved
Application Support:
IEEE 802.3; 1000Base-T; 100Base-T; 10Base-T ,622 Mbps ATM
